Brass Gold Plating SMP RF Connector Male Flange Mount Limited Detent 18GHz 50 Ohm

Large Image : Brass Gold Plating SMP RF Connector Male Flange Mount Limited Detent 18GHz 50 Ohm Get Best Price

Product Details:

Place of Origin:	Xi'an, China
Brand Name:	ELT
Certification:	Rohs，ISO Certificates
Model Number:	SMP-JFD153

Payment & Shipping Terms:

Minimum Order Quantity:	In stock
Price:	Depending on the quantity
Packaging Details:	1pcs/plastic bag;10bags/carton
Delivery Time:	6-8weeks for new production
Payment Terms:	T/T or LC
Supply Ability:	As requirements

Contact Now

Detailed Product Description

Product Name:	SMP RF Connector	Frequency:	DC~18GHz
Center Contact:	Brass， Gold Plated	Shell:	Brass， Gold Plated
Insulation Resistance:	5000 Ohm	DWV:	500V
Imdepence:	50Ω	Rated Voltage:	170V
Temperature Range:	-55℃~+125℃	Gender:	Male Plug
Dielectric:	PTFE	Mounting:	2-hole Flange Mount
Samples:	Available，2 Pcs In Stock	Interface:	Limited Detent
Pin OD:	0.3mm, 0.45mm, 0.5mm, 0.7mm, 0.9mm, 1.3mm Available
Highlight:	Brass SMP RF connector male flange mount , Gold plating SMP connector 18GHz , SMP RF connector 50 ohm

Product Description:

Copper Alloy Gold Plating SMP RF Connector Male Flange Mount Limited Detent 18GHz 50 Ohm

The SMP RF flange connector is a type of high-frequency PCB mount connector. It is commonly used in RF systems to provide a separable electrical connection between equipment, cables, or circuit boards. This connector features a characteristic impedance of 50Ω and an operating frequency range of up to 0~18GHz, making it suitable for high-frequency applications such as radar, communication base stations, satellite communication, and test and measurement.

This connector features a compact structure and excellent mechanical durability. Its electrical specifications include a Voltage Standing Wave Ratio (VSWR) of ≤1.3, insulation resistance of ≥1000MΩ, and dielectric strength of 500V, making it ideal for systems with high signal integrity requirements. The housing is typically made of gold-plated brass or stainless steel to ensure corrosion resistance and shielding effectiveness in complex environments.

Full Detent: Provides maximum retention force, ideal for critical, high-vibration environments.

Limited Detent: Balances security with ease of maintenance, perfect for routine serviceability.

Smooth Bore: Optimized for high-density arrays where space is at a premium.

Force Comparison: Insertion and extraction force follows the hierarchy: Full Detent > Limited Detent > Smooth Bore.

Outline Dimension of Copper Alloy Gold Plating SMP RF Connector male flange mount connector Model : SMP-JFD153

Brass Gold Plating SMP RF Connector Male Flange Mount Limited Detent 18GHz 50 Ohm 0

Model No.	Interface Form	Note
SMP-JFD153	Limited Detent	Engagement Depth: 2.79mm

Outline Dimension of Copper Alloy Gold Plating SMP RF Connector Plug 2 Hole Flange Mount Connector Model : SMP-JFD7

Brass Gold Plating SMP RF Connector Male Flange Mount Limited Detent 18GHz 50 Ohm 1

Model No.	Interface Form	Note
SMP-JFD7	Limited Detent	Engagement Depth: 2.79mm

Outline Dimension of Copper Alloy Gold Plating SMP RF Connector Plug 2 Hole Flange Mount Connector Model : SMP-JFD12

Brass Gold Plating SMP RF Connector Male Flange Mount Limited Detent 18GHz 50 Ohm 2

Model No.	Interface Form	Note
SMP-JFD12	Limited Detent	Engagement Depth: 2.79mm

Outline Dimension of Copper Alloy Gold Plating SMP RF Connector Plug 2 Hole Flange Mount Connector Model : SMP-JFD29

Brass Gold Plating SMP RF Connector Male Flange Mount Limited Detent 18GHz 50 Ohm 3

Model No.	Interface Form	Note
SMP-JFD29	Limited Detent	Engagement Depth: 2.79mm

Outline Dimension of Copper Alloy Gold Plated SMP RF Connector Plug 2-Hole Flange Mount Connector Model : SMP-JFD25

Brass Gold Plating SMP RF Connector Male Flange Mount Limited Detent 18GHz 50 Ohm 4

Note: we also have the pin OD =0.3, 0.45, 0.5, 0.7, 0.9, 1.3, please feel free to contact us if you need different size pins.
