SSMP Male Right Angle RF Connector Surface Mount With Microstrip Full Detent

SSMP Male Right Angle RF Connector Surface Mount With Microstrip Full Detent
SSMP Male Right Angle RF Connector Surface Mount With Microstrip Full Detent SSMP Male Right Angle RF Connector Surface Mount With Microstrip Full Detent SSMP Male Right Angle RF Connector Surface Mount With Microstrip Full Detent

Large Image :  SSMP Male Right Angle RF Connector Surface Mount With Microstrip Full Detent Get Best Price

Product Details:
Place of Origin: China
Brand Name: ELT (Elite)
Certification: CE ROHS
Model Number: SSMP-JWHD47
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: Standard Export Carton
Delivery Time: Within 3 weeks
Payment Terms: Western Union, L/C, T/T
Supply Ability: 1,000,000pcs per month
Detailed Product Description
Interface Depth: 2.11mm Rated Voltage: 85VRMS*
Material: Brass Plating: Gold Plated
Impedance: 50Ω Frequency Range: DC~60GHz
Interface: Full Detent Lifespan: 500Cycles
High Light:

SSMP Right Angle RF Connector

,

Surface Mount Right Angle RF Connector

,

Full Detent Right Angle RF Connector

SSMP Male Right Angle Surface Mount with Microstrip Full Detent RF Connector

The SMPM interface is a micro-miniature interface with a frequency range of DC to 50 GHz. It is commonly used in miniaturized high frequency coaxial modules and is offered in both push-on and snap-on mating styles.

The full detent and smooth bore mating systems provide respective levels of engagement/disengagement forces. This family of interconnects addresses small package design needs; it can be utilized as a highly shielded interconnect for high data rate applications or in a board-to-board system using a floating bullet adapter. This floating bullet provides a link between mated pairs compensating for both radial and axial misalignment.



Features

  • Small package size
  • Push-on and snap-on mating styles for quick installation
  • Designs available for board-to-board and cable-to-board configuration
Specification

Electrical Characteristics
Impedance 50Ω
Frequency Range DC~60GHz
Rated Voltage  85VRMS*
Dielectrics Voltage-resistance 250VRMS*
Insulation Resistance ≥2000MΩ
Center Resistance Outer conductor Normal≤2mΩ, Sealing≤5mΩ
Center conductor Normal≤6mΩ, Sealing≤25mΩ
  DC~18GHz 18~26.5GHz 26.5~40GHz 40~50GHz
VSWR ≤1.25 ≤1.3 ≤1.35 ≤1.4
Material & Mechanical Characteristics
Center Conductor Male Sn-P Bronze/Kovar, Gold plated
Female Beryllium bronze, Gold plated
Elastic Contact Beryllium bronze Gold plated
Shell and other Metal Parts

Brass/Kovar Gold plated

Stainless steel Passivation

Insulators Glass sintering/PTFE/PEI
Hermetic Product Leakage Rate ≤1.01325×10-3Pa·cm3/s



SSMP Male Right Angle RF Connector Surface Mount With Microstrip Full Detent 0

Application:



  • Antennas
  • Broadband
  • Wireless
  • Military
  • Instrumentation
  • Medical
  • Quantum Computing

Product Cataloge:



RF Adapter
Waveguide To Coaxial Adapter
TNC RF Connector
N Type RF Connector
Microwave Rotary Joints
RF Cable Assemblies
SMA/SSMA RF Connector
SMP/SSMP RF Connector
MCX/MMCX RF Connector
J30J Series Connector
Glass-to-metal Hermetic Seals
BNC RF ConnectorMillimeter Wave Connectors(2.4mm, 2.92mm)



Packaging Details:


* Standard Export Carton
* According to customers' requirements



NOTE:
We have over 10,000 types of SMPM Connector, if the connector you are using is not found, please contact us with your detai
ls.
