Nickel Plated TNC Female Right Angle Connector TNC Coax Connector VSWR ≤1.3

Nickel Plated TNC Female Right Angle Connector TNC Coax Connector VSWR ≤1.3
Nickel Plated TNC Female Right Angle Connector TNC Coax Connector VSWR ≤1.3 Nickel Plated TNC Female Right Angle Connector TNC Coax Connector VSWR ≤1.3 Nickel Plated TNC Female Right Angle Connector TNC Coax Connector VSWR ≤1.3 Nickel Plated TNC Female Right Angle Connector TNC Coax Connector VSWR ≤1.3

Large Image :  Nickel Plated TNC Female Right Angle Connector TNC Coax Connector VSWR ≤1.3 Get Best Price

Product Details:
Place of Origin: China
Brand Name: ELT (Elite)
Certification: ISO-9001-2015
Model Number: TNC Conector
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: Standard Export Carton
Delivery Time: Within 5-7 workdays(for stocks)
Payment Terms: T/T, Western Union, L/C
Supply Ability: 100,000 Pieces Per Month
Detailed Product Description
Product Name: TNC Conector Plating: Gold Plated/ Nickel Plated
Impedance: 50Ω Certificate: CE ROHS
Durability: 500 Cycles Contact Material: Brass, BeCu
Application: Microwave
Highlight:

tnc bulkhead connector

,

tnc coax connector

Straight/Right Angle TNC Male/Female Plug Connector to SMA Female Socket RF Coaxial Connector



TNC series product is designed as a threaded version of BNC connector, the TNC RF connectors features screw threads for mating.TNC connectors are miniature, threaded waterproof units with a constant 50Ohm impedance,operating from DC-11GHz, there are two types of TNC connectors: standard and reverse polarity.these low cost connector typically utilize die cast and molded components.While performance will not be equal to the industrial or high performance grade products, these connectors are ideal for use on a varity of commercial applications



Specification

Electrical Characteristics
Impedance
50Ω
Frequency Range
DC~4GHz
Rated Voltage
2500VRMS (Maximum sea-level)
Dielectrics Voltage-resistance
750VRMS (Maximum sea-level)
Insulation Resistance
≥2000MΩ
Contact Resistance
Outer conductor
≤6mΩ
Center conductor
≤1.5mΩ
VSWR
≤1.3



Mechanical Specification

Design Standard IEC 60169-17
RoHS Compliant Yes
Centre Contact Termination Crimp
Outer Contact Termination Crimp
Mating Cycles 500Cycles
Contact Retention 10N min
Cable Retention 100N min
Mating Force 13.6N max
Un-Coupling Force 13.6N max



Detailed Drawing





Nickel Plated TNC Female Right Angle Connector TNC Coax Connector VSWR ≤1.3 0

Nickel Plated TNC Female Right Angle Connector TNC Coax Connector VSWR ≤1.3 1



Application:

* Base Station
* Network
* Radar
* Antennas
* Telecom
* Computers
* High-speed cable modems
* Telecommunications
* Cellular mobile telephones
* Instrumentation



Product Cataloge:

RF Adapter
SMA/SSMA RF Connector
SMP/SSMP RF Connector
TNC RF Connector
N Type RF Connector
MCX/MMCX RF Connector
BNC RF Connector Millimeter Wave Connectors(2.4mm, 2.92mm)
RF Cable Assemblies
Waveguide to Coaxial Adapter
Glass-to-metal Hermetic Seals
J30J Series Connector
Microwave Rotary Joints



NOTE:
We have over 10,000 types of TNC connector, if the connector you are using is not found, please contact us with your detai
ls.
