50 Ohm Stainless Steel Straight SMA male/plug To SMP limited detent male/plug Adapters Frequency Up To 18 GHz
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Product Name: | SMP Male To SMP Male Adapter | Center Contact: | Copper Alloy， Gold Plated |
|---|---|---|---|
| Shell: | Stainless Steel，Passivation | Imdepence: | 50 Ohm |
| Rated Voltage: | 170V | DWV: | 500V |
| Insulation Resistance: | 5000 Ohm | Frequency: | DC~18GHz |
| Temperature Range: | -55℃~+125℃ | Samples: | Available，In Stock |
Product Description:
SMA male to SMP male 50 ohm Micro-miniature Adapters
These adpters are primarily intended for applications where minimum dimensions and space-saving designs are required. They are suitable for use up to 18 GHz .
The SMP connector family includes both straight and right-angle (RA) variants for cable or soldered PCB connections. Depending on the usage environment, users can select plugs with different structures:
- Full Detent Structure: Ideal for applications where frequent insertion is not required.
- Limited Detent Structure: Suitable for scenarios requiring frequent insertions.
- Smooth Bore Structure: Best for assembling multiple SMP board-to-board connectors.
Insertion and Pull-out Force: Full Detent > Limited Detent > Smooth Bore
Outline Dimension of Straight SMA to SMP male to male adapters SMA/SMP-JJG Series:
| Model | L (different length) | Note |
| SMA/SMP-JJG | 18mm max |
SMP end is limited detent,
interface depth is 2.79mm.
Stainless Steel Shell
|
| SMA/SMP-JJ | 18mm max |
SMP end is limited detent,
interface depth is 2.79mm.
Copper Alloy Shell
|
Note: If you would like to customize the different length of SMP to SMP Adapters, Bullets. please contact us freely through sales3@xa-elite.com.cn
Applications:
Xi'an Elite Electronic is a Leading Manufacturer of RF/Microwava /Wave-guide Connectors, Adapters & Cable Assemblies serving aerospace, aviation, navigation, satellite, radar, communications, electronics industry. Our high quality products use the finest materials and strict processes to ensure the durablility and reliablity in harsh environment.
Packing and Shipping:
Packaging:
Package Dimensions: Outer Small Carton with L 26.5*W18.5*H14cm
Shipping:
Shipping Time: 5-7 business days for stocked connectors and adapters. For the new production, once the goods are ready, we will arrange the shipment as earlier as we can.
