SUS Female 2.92mm RF Connector for CXN3506/MF108A Cable

Large Image : SUS Female 2.92mm RF Connector for CXN3506/MF108A Cable Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	ELT
Certification:	CE,ROHS
Model Number:	K-J506G

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiable
Packaging Details:	Standard Export Carton
Delivery Time:	Within 3 weeks
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	35000pcs/year

Contact Now

Detailed Product Description

Material:	Stainless Steel	Gender:	Male
Product Name:	2.92mm,K Type,SMK	Keywords:	Cable Connector
Item:	Millimeter Wave Connectors	Plating:	Nickel Plated
Application:	RF	Surface Plating:	Passivate
Highlight:	SUS 2.92mm RF Connector , 2.92mm RF Connector MF108A , 2.92mm RF Connector CXN3506

Stainless Steel K(2.92mm) Female RF Coaxial Connector for CXN3506/MF108A Cable

The 2.92mm coaxial female connector of Xi'an Elite Electronics is part of a very wide selection of RF interconnect components. The 2.92mm coaxial line bus connector of Xi'an Elite Electronics includes a bus type with 50Ohm impedance level. Our coaxial cable 2.92mm female connector has standard polarity design, including diaphragm type, 4-hole flange type and bracket free type.

The 2.92mm female connector product series for coaxial cables provides a variety of connection methods for clamping/non welding contact, clamping/welding, welding and welding/non welding contact. 2.92mm female connector for coaxial cable Compatible cable types include 2 # Semirigid/flexible/CXN3506/CXN3507/MF108A/MF363A

SUS Female 2.92mm RF Connector for CXN3506/MF108A Cable 0
Specification:

Impedance	50Ω
Frequency Range	DC - 40GHz
Voltage Rating	250 VRMS (Max. Sea Level)
Dielectric Withstanding Voltage	750 VRMS (Max. Sea Level)
Voltage Standing Wave Ratio VSWR	≤ 1.05 + 0.005f
Contact Resistance	Center Conductor ≤ 3.0 mΩ
	Outer Conductor ≤ 2.0 mΩ
Insulation Resistance	≥ 5000 MΩ

Inner Conductor	Male plug: Brass, Gold Plated
	Female Jack: Beryllium bronze, Gold Plated
Body / Shell / Housing	Brass, Gold Plated, Stainless Steel, Passivated
Insulator	PEI/PLF
Gasket	Silicone Rubber
Temperature	-55℃ ~ +125℃
Durability	500 Cycles
Torque	0.79 ~ 1.13 N.m

Features:
*High performance up to 40GHz
*Low VSWR
*Excellent return loss and insertion loss
*Ruggedized construction for repeatability
*Compitable to mate with SMA, 3.5 mm and other K or 2.92 mm connectors

Application:

*Optical test

*Laboratory and bench testing

*SATCOM

*Microwave

*Quantum computing

Related products:

SUS Female 2.92mm RF Connector for CXN3506/MF108A Cable 2

K-K506G

K female right angle stainless steel for CXN3506/MF108A

SUS Female 2.92mm RF Connector for CXN3506/MF108A Cable 3

K-JW506G
