Plating: | Gold-plated | Impedance: | 50Ω |
---|---|---|---|
Frequency: | DC~30GHz | Lifetime: | 500 Cycles |
Body: | Brass | Application: | Audio/Vedio/Microwave |
Rated Voltage: | 250VRMS | Medium Pressure: | 750VRMS |
Highlight: | 90 Degree SSMA RF Connector,MF068B Cable SSMA RF Connector,MF068B Cable 90 Degree RF Connector |
The specifications below are general specifications for all sma connectors. Specific specifications for VSWR, insertion loss, and RF leakage for each connector is available from our factory upon request.
RF coaxial connector is a Chinese term that refers to a type of connector used in radio frequency (RF) applications. It is commonly used to connect coaxial cables to electronic devices, such as antennas, amplifiers, and transmitters. These connectors are designed to maintain the integrity of the signal being transmitted, while also providing a secure and reliable connection. They are commonly used in telecommunications, broadcasting, and other industries that require high-frequency signal transmission.
RF coaxial connector is a type of electrical connector used for radio frequency (RF) signals. It is designed to maintain the shielding that the coaxial design offers, and provide a consistent impedance at the connection. It is commonly used in applications such as telecommunications, broadcasting, and computer networking.
Key Features:
Specifiacation of SSMA RF Connectors:
Electronic and Material Characterials | ||
Impedance | 50Ω | |
Frequency Range | DC~30GHz | |
Rated Voltage | 250 VRMS (Maximum sea-level) | |
Dielectrics Voltage-resistance | 750 VRMS (Maximum sea-level) | |
VSWR | ≤1.3 | |
Insulation Resistance | ≥2000MΩ | |
Center conductor | Male | Brass gold plated |
Female | Beryllium copper gold plated | |
Shell and other metal parts | Brass gold plated | |
Brass nickle plated | ||
Cable sheath | Brass nickle plated | |
Insulator | PTFE | |
Seal ring | Silicon rubber | |
Mating torque | 0.5 -0.7 N.m |
Application:
Related Product:
1. Mini SMA Microstrip series 2 Holes Flange Connectors
Model Number | L | L1 | L2 | L3 | L4 | D | D1 | D2 | D3 |
SSMA-KFD2 | 15.6 | 3.2 | 2.7 | 4.8 | 8.3 | 0.88 | 4.6 | 12.3 | 2.4 |
SSMA-KFD8 | 11.9 | 0 | 2.2 | 4.8 | 8.3 | 0.88 | / | 12.3 | 2.4 |
2.SMA Female RF Connectors for cable RG178
Model Number | Description |
SMA-KB2 | SMA female solder rf connector |
3.Mini SMA PCB Panel Mount 4 Holes Flange Connectors
Model Number | Description |
SSMA-KHD | Female SSMA RF connectr for PCB |
NOTE:
We have over 10,000 types of SMA Connector, if the connector you are using is not found, please contact us with your details.
