| Material: | Brass/Kovar Alloy/Stainless Steel | Plating: | Gold Plated/Passivation |
|---|---|---|---|
| Impedance: | 50Ω | Frequency Range: | DC~50GHz |
| Rated Voltage: | 170VRMS* | Interface: | Smooth Bore/ Full Detent |
| Insulating Medium: | Glass Sintering/PTFE/PEI | Insulation Resistance: | ≥2000MΩ |
| High Light: | SSMP RF Adapter,Smooth Bore RF Adapter,RF Adapter Female To Female |
||
Solder Attachment SMPM RF Connector Coaxial SSMP Male Connector
SSMP/SMPM is a miniature push-on RF coaxial connector, which have the characters of small volume(compared with Mini SMP), light weight, wide working broadband,etc. Apply for the couple usage of board to board connectors for the situation of modular intensive mounting, and the plug has two interface form with full detent and unthreaded hole.
| Electrical Characteristics | |||||
| Impedance | 50Ω | ||||
| Frequency Range | DC~50GHz | ||||
| Rated Voltage | 170VRMS* | ||||
| Dielectrics Voltage-resistance | 500VRMS* | ||||
| Insulation Resistance | ≥2000MΩ | ||||
| Center Resistance | Outer conductor | ≤5mΩ | |||
| Center conductor | ≤30mΩ | ||||
| DC~18GHz | 18~26.5GHz | 26.5~40GHz | 40~50GHz | ||
| VSWR | ≤1.25 | ≤1.3 | ≤1.4 | ≤1.5 | |
| Material & Mechanical Characteristics | |||||
| Center Conductor | Male | Kovar, Gold plated | |||
| Elastic Contact | Beryllium bronze Gold plated | ||||
| Shell and other Metal Parts |
Kovar Gold plated |
||||
| Insulators | Glass sintering | ||||
| Hermetic Product Leakage Rate | ≤1.01325×10-3Pa·cm3/s | ||||
Application:
* Computer/LANs
* Base Station
* Outdoor facilities
* Automotive
* Jump line join
* Basic facility
* Network
* Satcom
* Radar,microwave
* Telecommunications
* Mobile communication
* Instrumentation
* Radio, TV aerial system
