High & Low Frequency RF Hybrid Wire Connectors Integrated

High & Low Frequency RF Hybrid Wire Connectors Integrated
High & Low Frequency RF Hybrid Wire Connectors Integrated High & Low Frequency RF Hybrid Wire Connectors Integrated High & Low Frequency RF Hybrid Wire Connectors Integrated

Large Image :  High & Low Frequency RF Hybrid Wire Connectors Integrated Get Best Price

Product Details:
Place of Origin: China
Brand Name: ELT
Certification: CE ROHS
Model Number: ELT-J57P -T6G6D~J57P-Z6G6D
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: Standard Export Carton
Delivery Time: Within 3 weeks
Payment Terms: T/T, Western Union, L/C
Supply Ability: 10,000pcs Per Month
Detailed Product Description
Product: Integrated Connector Certificate: CE ROHS
Conductor: Copper Alloy/Gold-plated VSWR: ≤1.3
Application: Array Surveillance Radar System Temperature Range: -55°C~+125°C
Insulating Medium: PTFE Impedance: 50Ω
Shell: Aluminum Alloy/Nickel Plating Insulation Resistance: 5000MΩ
High Light:

RF Hybrid Wire Connectors

,

Integrated Hybrid Wire Connectors

,

Low Frequency Hybrid Wire Connectors

High Density DC and Control Signals and RF signals Integrated Connector



Integrated connectors are miniaturized, lightweight connectors designed to achieve simultaneous transmission of multichannel signals. They are applicable to multi-signal transmission occasions where the space is limited, so the weight and environment characteristics of connectors are critical.

Our integrated connectors can be classified into RF integrated connectors and high & low frequency hybrid integrated connectors. Our integrated connectors are push-on screw-threaded coupling with metal outer conductor. Interfaces of our RF integrated connectors comply with GJB5246; Interfaces of our hybrid integrated connectors can be customized.

Integrated connectors are designed with compact size, keying for incorrect connections, reliable contact, shock resistance, anti-vibration, salt-spray resistance, high performance at high frequency, etc.



Specification
Frequency Range  0.04GHz-18GHz
High Frequency  6 pins
Low Frequency  6 pins
VSWR ≤1.3
Voltage Resistance 500V
Custom Size Available
Cable for RF CXN3506
Cable for Low  AFR-250  0.5mm²
Rated Current  7.5A
