|Product Name:||SMA RF Adapter||Plating:||Gold Plated|
|Durability:||500 Cycles||Application:||RF, Satcom /antenna/Audio|
|Contacts:||Beryllium Bronze||Certificate:||ROHS, ISO-9001-2015|
|Torque:||0.79 ~ 1.13 N.m|
Gold Plated SMA RF Connector,
RP SMA RF Connector,
rp sma male to sma male adapter
Reverse polarity RF coaxial connectors:
It is developed for the purpose of some particular conditions to prevent misplug. The characteristic is that center conductor male and female is opposite to original type, but the electrical and mechanical characteristics are the same with original series products. ELT mainly reverse polarity product are . Meanwhile, customized other series reverse polarity product is also accepted.
High Performance SMA RF Connectors:
1. SMA RF connectors are available in quick connect , push-on or standard interface , straight, 90 degrees versions,as well as bulkhead or 4 hole panel configurations.
2. SMA RF connector is high quality and quick combinations by simply screwing two connectors together, with no soldering or crimping required.
3. SMA electrical connectors are widely used for microwave, antennas and testing instrumentation etc.
4. SMA RF connector are threaded-coupling RF coaxial connectors with miniature size, vibration-proof and wide frequency range up to 18 GHz (Our SMA RF connectors can be 20 GHz).
|Center Resistance||Center Conductor||≤3.0mΩ|
Material & Mechanical Characteristics:
|Center Conductor||Male||Brass Gold plated|
|Female||Sn-P Bronze Gold plated|
|Elastic Contact||Beryllium bronze Nickel plated|
|Shell and other Metal Parts||Brass Nickel plated|
|Crimping Sleeve||Brass Nickel plated|
|Tightening torque of connection||0.79－1.13N .m|
|Sealing Ring||Silicone Rubber|
More Detail of
Gold Plated RPSMA Male to SMA Male RF Coaxial Connector Adapter:
We have over 10,000 types of SMA Connector, if the connector you are using is not found, please contact us with your details.
