50Ω SMP Female Jack Bulkhead SMP RF Connector up to 18GHz

Large Image : 50Ω SMP Female Jack Bulkhead SMP RF Connector up to 18GHz Get Best Price

Product Details:

Place of Origin:	Xi'an, China
Brand Name:	ELT
Certification:	Rohs，ISO Certificates
Model Number:	SMP-KYD

Payment & Shipping Terms:

Minimum Order Quantity:	In stock
Price:	Depending on the quantity
Packaging Details:	1pcs/plastic bag;10bags/carton
Delivery Time:	6-8weeks for new production
Payment Terms:	T/T or LC
Supply Ability:	As requirements

Contact Now

Detailed Product Description

Product Name:	SMP RF Connector	Center Contact:	Copper Alloy， Gold Plated
Shell:	Copper Alloy， Gold Plated	Frequency:	DC~18GHz
DWV:	500V	Rated Voltage:	170V
Imdepence:	50Ω	Insulation Resistance:	5000 Ohm
Temperature Range:	-55℃~+125℃	Gender:	Female
Mounting:	Bulkhead Mount	Dielectric:	PTFE
Samples:	Available，In Stock
Highlight:	50Ω SMP female RF connector , SMP bulkhead RF connector , 18GHz SMP RF connector

Product Description:

50Ω SMP Female Jack Bulkhead SMP RF Connector up to 18GHz

Elite Electronics' SMP RF connectors support up to 40 GHz for superior signal integrity. Their tool-free push-on design speeds up installation. With straight, right-angle, and flange options for PCB or cable assemblies, they meet diverse sealing needs. Choose from three male plug types: Full Detent (max retention force), Limited Detent (easy maintenance), or Smooth Bore (high-density using). Insertion and extraction force: Full Detent > Limited Detent > Smooth Bore

Outline Dimension of Straight SMP RF Connector Female Bulkhead Connector SMP-KYD:

50Ω SMP Female Jack Bulkhead SMP RF Connector up to 18GHz 0

50Ω SMP Female Jack Bulkhead SMP RF Connector up to 18GHz 1

50Ω SMP Female Jack Bulkhead SMP RF Connector up to 18GHz 2

Applications:

Xi'an Elite Electronics is a Leading Manufacturer of RF/Microwava /Wave-guide Connectors, Adapters & Cable Assemblies serving aerospace, aviation, navigation, satellite, radar, communications, electronics industry.
50Ω SMP Female Jack Bulkhead SMP RF Connector up to 18GHz 3

Packing & Shipping:

Packaging:

Package Dimensions: Outer Small Carton with L 26.5*W18.5*H14cm

Shipping:

Shipping Time: 5-10 working days for stocked RF Coaxial Adapters Connector. For the new production, it will takes about 6-10 weeks, The delivery time we provide is conservative to ensure product quality before shipment.

50Ω SMP Female Jack Bulkhead SMP RF Connector up to 18GHz 4
