Product Details:
Payment & Shipping Terms:
|
| Material: | Stainless Steel | Gender: | Female |
|---|---|---|---|
| Product Name: | 2.92mm,K Type,SMK | Keywords: | Cable Connector |
| Item: | Millimeter Wave Connectors | Plating: | Nickel Plated |
| Application: | RF | Surface Plating: | Passivate |
| High Light: | SS 2.92 Mm K Connector,Female 2.92 Mm K Connector,Semi Rigid 2.92 Mm K Connector |
||
K(2.92mm) Female Stainless Steel Material RF Coaxial Connector for 2#Semi-rigid/flexible Cable
2.92mm Female Connectors for Coax from Xi'an Elite Electronic are part of the very extensive selection of radio frequency interconnect components. Xi'an Elite Electronic 2.92mm Female Connectors for Coax include female genders in 50Ohm impedance levels. Our 2.92mm female connectors for coax are available in standard polarity designs with bulkhead, 4 holes flange and mountless types.
The 2.92mm female connectors for coax product line for coax are available with various clamp/non-solder contact, clamp/solder, solder and solder/non-solder contact attachment methods.2.92mm Female Connectors for Coax connector compatible cable types include: 2#Semirigid/flexible/CXN3506/CXN3507/MF108A/MF363A.
Specification:
| Impedance | 50Ω |
| Frequency Range | DC - 40GHz |
| Voltage Rating | 250 VRMS (Max. Sea Level) |
| Dielectric Withstanding Voltage | 750 VRMS (Max. Sea Level) |
|
Voltage Standing Wave Ratio |
≤ 1.05 + 0.005f |
| Contact Resistance | Center Conductor ≤ 3.0 mΩ |
| Outer Conductor ≤ 2.0 mΩ | |
| Insulation Resistance | ≥ 5000 MΩ |
| Inner Conductor | Male plug: Brass, Gold Plated |
| Female Jack: Beryllium bronze, Gold Plated | |
| Body / Shell / Housing |
Brass, Gold Plated, Stainless Steel, Passivated |
| Insulator | PEI/PLF |
| Gasket | Silicone Rubber |
| Temperature | -55℃ ~ +125℃ |
| Durability | 500 Cycles |
| Torque | 0.79 ~ 1.13 N.m |
Features:
*High performance up to 40GHz
*Low VSWR
*Excellent return loss and insertion loss
*Ruggedized construction for repeatability
*Compitable to mate with SMA, 3.5 mm and other K or 2.92 mm connectors
Application:
*Optical test
*Laboratory and bench testing
*SATCOM
*Microwave
*Quantum computing
Related products:
| K-JW87G | K male right angle stainless steel for 2#Semi-flex Cable Assembly |
| K-J87G | K male stainless steel for 2# Semi-rigid/flex cable assembly |
