| Impedence: | 50 Ohm | Length: | 18.3mm Max |
|---|---|---|---|
| Diameter: | φ7.8 | Frequency Range: | DC-40GHz |
| Housing: | Brass | Note: | Cylindrical Resistor |
| High Light: | Male Brass RF Coaxial Connector,Load Termination RF Coaxial Connector,1W RF Coaxial Cable Connector Adapter |
||
SOSMA Male Brass 1W RF Matched Load Termination
From test and measurement to military and aerospace, RF terminals/RF loads are essential components that run through the RF signal chain. In essence, RF loads and terminals describe the same type of components, that is, passive components that absorb RF energy at the terminals of the signal chain branches. In most applications, The load impedance of the RF terminal is the same AS the intrinsic impedance of the transmission line used for interconnection between the terminal and upstream components/equipment. In this way, an open-ended or unused port, such as an unwanted forward or reverse port in a directional coupler, can be terminated to prevent unwanted reflected signals from returning from the termination and affecting upstream signal chain components.
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||
Details of CSMP Female Brass 0.5W RF Matched Load Termination
Advantage :
* High Reliable
* Reliable Mechanical Performance
* Wide Frequency Range from DC to 40GHz
Applications :
* Aerospace
* Military
* Broadband
* Instrumentation
* Routers
* Telecommunications
* High-Speed Applications (10 to 40 Gbits)
* Cable Assembly
* PCB
* Surface Mount Connections
* Features and Benefits
Since the matched load needs to be customized according to your needs, please provide the following requirements when you send us inquiry:
*The frequency range you need.
*Power requirement.
*Connector type
*Your special requirements if you have (VSWR, temperature, size, etc.)
Related RF Loads:
Rf terminals/loads are of various types and are available for coaxial and waveguide interface types. One of the main characteristics of RF terminals is the specific coaxial type or waveguide size, as well as the power handling capability of the terminal. Typically, power handling capabilities are limited by the type of coaxial or waveguide connector, the type of RF load within the terminal, and the thermal management design of the terminal. Some RF terminals have additional features such as retaining chains, environmental sealing gaskets, and specific metal coatings to enhance corrosion resistance. Although generally not applicable to every coaxial RF terminal type, some coaxial RF terminals are also double-ended, each with a different coaxial connector type. This feature allows multiple coaxial connector ports to be terminated without the need for additional terminals or coaxial adapters.
