Flange Mount SBMA Plug Straight RF Coax Connector

Flange Mount SBMA Plug Straight RF Coax Connector
Flange Mount SBMA Plug Straight RF Coax Connector Flange Mount SBMA Plug Straight RF Coax Connector Flange Mount SBMA Plug Straight RF Coax Connector Flange Mount SBMA Plug Straight RF Coax Connector Flange Mount SBMA Plug Straight RF Coax Connector

Large Image :  Flange Mount SBMA Plug Straight RF Coax Connector Get Best Price

Product Details:
Place of Origin: China
Brand Name: ELT (Elite)
Certification: CE ROHS
Model Number: SBMA-JFD4
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: Negotiable
Packaging Details: Standard Export Carton
Delivery Time: Within 3 weeks
Detailed Product Description
Product Name: SBMA RF Conector Plating: Nickel / Gold Plated
Durability: 500 Cycles Contact Material: Brass, BeCu
Material: Brass Design Standard:: IEC 1169-33
Type: Straight Gender: Male
High Light:

Flange Mount RF Coax Connector

,

SBMA Plug RF Coax Connector

,

SBMA Plug small coax connector

China Supplier Flange Shoulder SBMA Plug and Socket Straight RF Coaxial Connector​



SBMA series is a miniaturized product of the BMA series coaxial connectors, it's also blind-mate connectors, with the advantages of good bandwidth, small occupy space can meet the requirements of microwave device miniaturization and modularization



Flange Mount SBMA Plug Straight RF Coax Connector 0

Specification


Electrical Characteristics
Impedance 50 Ohm
Frequency Range DC~40GHz
Rated Voltage 170 VRMS (Maximum sea-level)
Dielectrics Voltage-resistance 500 VRMS (Maximum sea-level)
Insulation Resistance ≥2000MOhm
Contact Resistance Outer conductor ≤2mOhm
Center conductor ≤6 mOhm
VSMR 1.25
Insertion Loss ≤0.30dB

Product Detail
 Flange Mount SBMA Plug Straight RF Coax Connector 1



Material & Mechanical Characteristics
Center Conductor Male/Plug Brass Gold plated
Female/Socket Sn-P bronze Gold plated
Resilience Contact Beryllium bronze Nickel Plated
Shell / Housing Brass,stainless steel Nickel Plated
Insulators PTFE
Sealing Ring Silicone Rubber
Durability 500 cycles





RoHS Compliant Yes
Mating Cycles 500Cycles
Contact Retention 10N min
Cable Retention 100N min
Mating Force 0.6N max
Un-Coupling Force 0.6 N max


Environmental Specification:


Operating Temperature -65 to +165Deg C
IP Rating ( Mated ) IP64




Features:


- Low cost combined with high quality.

- Broadband performance with low reflection from DC to 18 GHz.

- 50 Ohm impedance
- Accommodates a wide range of miniature RG flexible semi-rigid coaxial cables
- BNC connectors are available in straight or right angle versions as well as, bulkhead, 2 holes panel, 4 holes panel or mountless options.

- Available for affixement to industry standard cable and as a printed circuit board device

- Provide repeatable performance


Application:


* Broadband

* Instrumentation

* Antennas

* Telecom

* Computers

* Broadcast

* Video systems

* Automotive

* Telecommunications

* Wireless industries

* Measurement equipment




NOTE:

We have over 10,000 types of interconnect products((BNC,TNC,MCX,MMCX,SMA,SSMA,SMB,SSMB,BMA,SBMA,SMC,SC,SMP,SSMP ect.),), if the connector you are using is not found, please contact us with your details.
