Gold Plated Male Plug PCB Mount SMA RF Connectors/SMA Coaxial Connector

Gold Plated Male Plug PCB Mount SMA RF Connectors/SMA Coaxial Connector
Gold Plated Male Plug PCB Mount SMA RF Connectors/SMA Coaxial Connector Gold Plated Male Plug PCB Mount SMA RF Connectors/SMA Coaxial Connector Gold Plated Male Plug PCB Mount SMA RF Connectors/SMA Coaxial Connector Gold Plated Male Plug PCB Mount SMA RF Connectors/SMA Coaxial Connector

Large Image :  Gold Plated Male Plug PCB Mount SMA RF Connectors/SMA Coaxial Connector Get Best Price

Product Details:
Place of Origin: China
Brand Name: ELT (Elite)
Certification: CE ROHS
Model Number: SMA-JF1
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: Negotiable
Packaging Details: Standard Export Carton
Delivery Time: Within 3 weeks
Payment Terms: L/C, T/T, Western Union
Supply Ability: 35000pcs/years
Detailed Product Description
Product Name: SMA RF Connector Plating: Gold Plated
Durability: 500 Cycles Contact Material: Brass, BeCu
Material: Brass Design Standard:: IEC60169-15
Type: Straight Gender: Female
High Light:

sma bulkhead connector

,

sma coax connector

Gold Plated Male Plug PCB Mount SMA RF Connectors/SMA Coaxial Connector


SMA Series RF coaxial connector is a kind of small, high frequency coaxial connector, which has the advantages of small size, wide frequency band,superior mechanical and electrical performance, high reliability and so on. it's developed and produced according to MIL-C-39012. SMA is the most widely used rf coaxial connectors in different fields of microwave communication and microwave measuring device.The high performance connector developed by our company can reach to 20GHz.

Gold Plated Male Plug PCB Mount SMA RF Connectors/SMA Coaxial Connector 0


Specification:

Electrical data Requirements
Impedance 50Ω
Frequency Range Connect with solf cable DC~12.4GHz
Connect with semi-rigid cable DC~18GHz
Rated Voltage 335VRMS
Dielectrics Voltage-resistance 1000VRMS
Insulation Resistance ≥5000MΩ
Center Resistance Center Conductor ≤3.0mΩ
Outer Conductor ≤2.0mΩ
VSWR ≤1.3



Material &Mechanical data Requirements
Center Conductor Male Brass Gold plated
Female Sn-P Bronze Gold plated
Elastic Contact Beryllium bronze Nickel plated
Shell and other Metal Parts Brass Nickel plated
Stainless Passivation
Crimping Sleeve Brass Nickel plated
Insulators PTFE
Sealing Ring Silicone Rubber
Durability 500 cycles
Tightening torque of connection 0.79-1.13N .m
Operating Temperature -45 to +125Deg C





Prooduct Detail:
 Gold Plated Male Plug PCB Mount SMA RF Connectors/SMA Coaxial Connector 1Gold Plated Male Plug PCB Mount SMA RF Connectors/SMA Coaxial Connector 2


Features:

1, SMA RF connectors are available in quick connect , push-on or standard interface , straight, 90 degrees versions,as well as bulkhead ,or 4 holes panel configurations.
2, SMA RF connector is high quality and quick combinations by simply screwing two connectors together, with no soldering or crimping required.
3, SMA electrical connectors are widely used for microwave, antennas and testing instrumentation etc.
4, SMA RF connector are threaded-coupling RF coaxial connectors with miniature size, vibration-proof and wide frequency range up to 18GHz (Our SMA RF connectors can be 20GHz).

Application:

* Broadband
* Instrumentation
* Antennas
* Telecom

* Aerospace
* Phased array antennas
* Telecommunications

* Board-to-board interconnect


Product Cataloge:



RF Adapter
SMA/SSMA RF Connector
SMP/SSMP RF Connector
TNC RF Connector
N Type RF Connector
MCX/MMCX RF Connector
BNC RF Connector Millimeter Wave Connectors(2.4mm, 2.92mm)
RF Cable Assemblies
Waveguide to Coaxial Adapter
Glass-to-metal Hermetic Seals
J30J Series Connector
Microwave Rotary Joints


NOTE:

We have over 4000 types of interconnect products, if the connector you are using is not found, please contact us with your details.

Contact Details
Xi'an Elite Electronic Industry Co., Ltd.

Contact Person: Elite

Tel: +8618437926277

Send your inquiry directly to us
